Product Details:
|
Material: | Tungsten Carbide | Application: | Metal/wood Cutting |
---|---|---|---|
ISO Grade: | K20 | Hardness: | HV30 1550 |
TRS: | 1550 | Density: | 14.91 |
Tolerance: | ISO 2768 M | ||
High Light: | K20 Tungsten Carbide Sheet,Two Bevels Tungsten Carbide Sheet |
Two Bevels Tungsten Carbide Strips K20 For Wood Cutting Metal Cutting Plates
Two bevels carbide strips
L mm | W mm | T mm | L mm | W mm | T mm | L mm | W mm | T mm | ||
310 | 4 | 2 | 310 | 20 | 3 | 310 | 34 | 4 | ||
310 | 5 | 2 | 310 | 22 | 3 | 310 | 35 | 4 | ||
310 | 6 | 2 | 310 | 24 | 3 | 310 | 40 | 4 | ||
310 | 8 | 2 | 310 | 30 | 3 | |||||
310 | 10 | 2 | 310 | 35 | 3 | 310 | 6 | 5 | ||
310 | 12 | 2 | 310 | 40 | 3 | 310 | 8 | 5 | ||
310 | 14 | 2 | 310 | 10 | 5 | |||||
310 | 15 | 2 | 310 | 6 | 4 | 310 | 12 | 5 | ||
310 | 16 | 2 | 310 | 8 | 4 | 310 | 13 | 5 | ||
310 | 18 | 2 | 310 | 10 | 4 | 310 | 14 | 5 | ||
310 | 20 | 2 | 310 | 12 | 4 | 310 | 15 | 5 | ||
310 | 25 | 2 | 310 | 13 | 4 | 310 | 16 | 5 | ||
310 | 30 | 2 | 310 | 14 | 4 | 310 | 18 | 5 | ||
310 | 35 | 2 | 310 | 15 | 4 | 310 | 20 | 5 | ||
310 | 40 | 2 | 310 | 16 | 4 | 310 | 22 | 5 | ||
310 | 18 | 4 | 310 | 23 | 5 | |||||
310 | 6 | 3 | 310 | 20 | 4 | 310 | 24 | 5 | ||
310 | 8 | 3 | 310 | 22 | 4 | 310 | 25 | 5 | ||
310 | 10 | 3 | 310 | 23 | 4 | 310 | 26 | 5 | ||
310 | 12 | 3 | 310 | 24 | 4 | 310 | 28 | 5 | ||
310 | 14 | 3 | 310 | 25 | 4 | 310 | 30 | 5 | ||
310 | 15 | 3 | 310 | 26 | 4 | 310 | 32 | 5 | ||
310 | 16 | 3 | 310 | 28 | 4 | 310 | 34 | 5 | ||
310 | 18 | 3 | 310 | 30 | 4 | 310 | 35 | 5 | ||
310 | 19 | 3 | 310 | 32 | 4 | 310 | 40 | 5 |
One bevel with 30° and 45°
Width: +0/+0.1Tolerance for length +0./+1.0
Thickness +0/+0.2
Straightness <0.15
Grade K20, with Cobalt: 8%
Tic/Tac: 1
Density: 14.91
Hardness: 2000
Grain size: Medium
OED Carbide strips:
Suitable for cutting wooden, metal, plastic, rubber, and so on.
OED recommended grades:
Application Code |
Chemical Composition | Physical and mechanical properties and microstructure as sintered |
Application recommended | |||||||
Co | Tic/ Tac |
WC | Density | Hardness | Transverse rupture strength |
Coercivity | Magnetic saturation |
Porosity | ||
g/cm3 | HV 30 | N/mm2 | KA/m | % | ||||||
K05 | 6 | 0.3 | 93.7 | 14.94 | 1650-1750 | ≥1560 | 19.5-24.5 | 5.1-5.9 | A02 B00 | For machining super-hard grey cast steel, hardening steel, chilled iron, high silicon-aluminum alloy, high wear-resistant plastic, hard paper plate and ceramics. |
6 | 2 | 92 | 14.95 | 1350-1500 | ≥1600 | 21.5-26.5 | 4.9-5.9 | A02 B00 | ||
K10-K15 | 6 | 0.4 | 93.6 | 14.91 | 1665-1835 | ≥1230 | 19.5-24.5 | 5.2-6.2 | A02 B00 | For machining cast iron with hardness higher than 200HB, short-chip forgeable cast iron, silicon-aluminum alloy, copper alloy, plastic, glass, ceramics, and stones. |
K20 | 6 | 0.4 | 93.6 | 14.9 | 1600-1700 | ≥1670 | 16.3-19.2 | 5.2-6.0 | A02 B00 | For machining grey cast iron with hardness lower than 200HB, non-ferrous metal, copper, brass, and aluminum |
7.8 | 1 | 91.2 | 14.61 | ≥1400 | ≥2000 | 15.0-18.0 | 6.6-7.8 | A02 B00 | ||
K30 | 6 | 2 | 92 | 14.8 | 1450-1600 | ≥1320 | 13.5-15.1 | 5.3-6.0 | A02 B00 | For machining low-hardness grey cast iron, low-strength steel and compact wood. |
Our advantages:
CIP Forming can eliminate the internal defects of raw sintered carbide blanks in particular. It can provide uniform density suppression products for the thick carbide strips/plate and special shape carbide products.
The internal stress can be removed through the cryogenic process to improve the microstructure.
The internal stress can be removed through the vibration process to improve the overall performance.
The service can be improved through the heat treatment process.
CIP forming.
CIP Forming can eliminate the internal defects of raw sintered carbide blanks in particular. It can provide uniform density suppression products for the thick carbide strips/plate and special shape carbide products.
Why choose us for carbide wear parts:
